Turn your PCIe M.2 NVMe or SATA AHCI M.2 SSD into a highly portable, USB-based external storage solution. This enclosure features USB 3.1 Gen 2 (10Gbps) with UASP support & PCIe 3.0 delivering real read/write data transfer speeds up to 1GB per second. Working with both PCIe and SATA based drives, this enclosure ensures compatibility with many M.2 drives, supporting both M-Key (PCIe) and B+M-Key (SATA) drives sized 2230/2242/2260/2280. The enclosure is also forward compatible with PCIe 4.0 based drives, at reduced PCIe 3.0 performance. USB 3.1 Gen 2 10Gbps (also known as USB 3.2 Gen 2x1) is backward compatible with USB 3.1 Gen 1 5Gbps (also known as USB 3.0), USB 2.0, and USB 1.1.
| Product Description | StarTech.com USB-C 10Gbps to M.2 NVMe or M.2 SATA SSD Enclosure, Tool-free M.2 PCIe/SATA NGFF SSD Enclosure, Portable Aluminum Case, USB Type-C & USB-A Host Cables, For 2230/2242/2260/2280 - Works w/ Thunderbolt 3 (M2-USB-C-NVME-SATA) - storage enclosure - M.2 Card (PCIe NVMe & SATA) - USB-C 3.2 (Gen 2) |
| Device Type | Storage enclosure - external |
| Bus Type | USB-C 3.2 (Gen 2) |
| Colour | Space grey |
| Expansion Bays | 1 x internal - M.2 NGFF 2230/2242/2260/2280 |
| Hard Drive Form Factor Compatibility | M.2 |
| Interface | M.2 Card (PCIe NVMe & SATA) |
| Data Transfer Rate | 10 Gbit/s |
| Supported Devices | Solid state drive |
| Max Storage Devices Qty | 1 |
| Product Material | Aluminium |
| Power Source | USB bus |
| Dimensions (WxDxH) | 10.5 cm x 3.5 cm x 1.4 cm |
| Weight | 52 g |
General | |
| Device Type | Storage enclosure - external |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | USB-C 3.2 (Gen 2) |
| Product Material | Aluminium |
| Colour | Space grey |
Storage Controller | |
| Interface | M.2 Card (PCIe NVMe & SATA) |
| Data Transfer Rate | 10 Gbit/s |
| Supported Devices | Solid state drive |
| Max Storage Devices Qty | 1 |
Expansion / Connectivity | |
| Bays | 1 x internal - M.2 NGFF 2230/2242/2260/2280 |
| Interfaces | 1 x SATA 6Gb/s / PCIe 4.0 (NVMe) - M.2 M+B/M Key (internal) |
| Connections | 1 x USB 3.2 (Gen 2) - 24 pin USB-C |
Miscellaneous | |
| Included Accessories | Thermal pad, SSD fastener pegs |
| Cables Included | 1 x USB-C to USB-C cable - external - 30 cm , 1 x USB-C to USB-A cable - external - 30 cm |
| Features | Supports AHCI mode, LED indicator, 4Kn drive compatible, TRIM support |
| MTBF | 112,000 hours |
| Compliant Standards | UASP (USB Attached SCSI Protocol) |
Power | |
| Power Source | USB bus |
Dimensions & Weight | |
| Width | 10.5 cm |
| Depth | 3.5 cm |
| Height | 1.4 cm |
| Weight | 52 g |
Dimensions & Weight (Shipping) | |
| Shipping Width | 17 cm |
| Shipping Depth | 14.2 cm |
| Shipping Height | 2.8 cm |
| Shipping Weight | 75 g |
Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
